03110 - Active Steering Control Module = ABS TMPS

**AudiA4B827** · 5 Października 2021

Witam

Dzisiaj przy skręceniu kierownicą nagle pojawił się jakiś lekki zgrzyt, wyskoczyła kontrolka kierownicy, następnie ESP + TMPS.

VCDS pokazał miliard błędów odnośnie ABS, ESP, TMPS, braku komunikacji modułów itp. Komputer podpinany w zasadzie zaraz przed skręceniem kierownicą.

Jeden szczególnie przykuł moją uwagę, bo w sumie od tego się zaczęło.

Address 03: ABS Brakes (J104) Labels:. 8K0-907-379-V1.clb
Part No SW: 8K0 907 379 M HW: 8K0 907 379 M
Component: ESP8 front H03 0210
Revision: -------- Serial number: --------------
Coding: 1A6D00
Shop #: WSC 80093 222 69422
VCID: 4385FA0BC295D1939E-8016

1 Fault Found:
03110 - Active Steering Control Module (J792)
013 - Check DTC Memory
Freeze Frame:
Fault Status: 01101101
Fault Priority: 6
Fault Frequency: 1
Reset counter: 51
Mileage: 200269 km
Time Indication: 0
Date: 2021.10.05
Time: 18:56:10

Freeze Frame:
Hex Value: 0x0000
Hex Value: 0x47A2
Hex Value: 0x000D
Hex Value: 0x33AB
Hex Value: 0x00FF

Czy w kierownicy lub jej obudowie jest jakiś czujnik który mógł po prostu sie odkręcić?

**wrclaguna** · 6 Października 2021

musisz odczytac błedy w (J792)

**AudiA4B827** · 6 Października 2021

2 godziny temu, wrclaguna napisał:

musisz odczytac błedy w (J792)

jak to zrobic?

**Muskel1** · 6 Października 2021

VCDSem. Sterownik j792 to sterownik 1B od aktywnego wspomagania. Zrób pełny autoscan i wrzuć go tutaj

**AudiA4B827** · 8 Października 2021

Friday,08,October,2021,17:44:51:00009
VCDS -- Windows Based VAG/VAS Emulator Running on Windows 10 x64
VCDS Version: 21.3.0.0
Data version: 20210226 DS325.0
www.Ross-Tech.com

VIN: WAUZZZ8K28A004724 License Plate:

Chassis Type: 8K-AU48 (8T0)
Scan: 01 02 03 05 07 08 09 0E 10 13 14 15 16 17 19 1B 36 37 3C 42
46 47 52 53 55 56 5C 62 6C 72 77

VIN: WAUZZZ8K28A004724 Mileage: 200320km-124473miles

01-Engine -- Status: Malfunction 0010
02-Auto Trans -- Status: OK 0000
03-ABS Brakes -- Status: Malfunction 0010
04-Steering Angle -- Status: OK 0000
05-Acc/Start Auth. -- Status: Malfunction 0010
07-Control Head -- Status: OK 0000
08-Auto HVAC -- Status: OK 0000
09-Cent. Elect. -- Status: Malfunction 0010
0E-Media Player 1 -- Status: OK 0000
10-Park/Steer Assist -- Status: OK 0000
13-Auto Dist. Reg -- Status: Malfunction 0010
14-Susp. Elect. -- Status: OK 0000
15-Airbags -- Status: OK 0000
16-Steering wheel -- Status: Malfunction 0010
17-Instruments -- Status: OK 0000
19-CAN Gateway -- Status: OK 0000
1B-Active Steering -- Status: OK 0000
36-Seat Mem. Drvr -- Status: Malfunction 0010
37-Navigation -- Status: OK 0000
3C-Lane Change -- Status: Malfunction 0010
42-Door Elect, Driver -- Status: OK 0000
46-Central Conv. -- Status: Malfunction 0010
47-Sound System -- Status: OK 0000
52-Door Elect, Pass. -- Status: OK 0000
53-Parking Brake -- Status: OK 0000
55-Headlight Range -- Status: Malfunction 0010
56-Radio -- Status: OK 0000
5C-Lane Maintain. -- Status: Malfunction 0010
62-Door, Rear Left -- Status: Malfunction 0010
6C-Back-up Cam. -- Status: Malfunction 0010
72-Door, Rear Right -- Status: OK 0000
77-Telephone -- Status: Malfunction 0010

-------------------------------------------------------------------------------
Address 01: Engine (J623-CAMA) Labels:| 059-907-401-V1.clb
Part No SW: 8K1 907 401 D HW: 8K0 907 401
Component: 2.7TDI EDC17 H01 0004
Revision: --H01---
Coding: 0104002C02070220
Shop #: WSC 80093 222 69422
ASAM Dataset: EV_ECM27TDI8K1907401D A01004
ROD: EV_ECM27TDI8K1907401D.rod
VCID: 2D51BCB37C1137E358-8078

3 Faults Found:
4327 - Function Restriction due to Faults in Other Modules
U1113 00 [047] - -
Confirmed - Tested Since Memory Clear
Freeze Frame:
Fault Status: 00000001
Fault Priority: 2
Fault Frequency: 2
Mileage: 200318 km
Date: 2021.10.08
Time: 16:58:17

Engine RPM: 639.00 /min
Normed load value: 37.3 %
Vehicle speed: 0 km/h
Coolant temperature: 63 °C
Intake air temperature: 27 °C
Ambient air pressure: 1000 mbar
Voltage terminal 30: 14.160 V
Unlearning counter according OBD: 40
Crankshaft speed (RPM): 639.0 /min
Vehicle speed: 0.00 km/h
Acceleration: 0.000 m/s˛
ACCI a Des: 0.007 m/s˛
ACCI st State-Bits 0-7: 00000011
Cruise Control System (CCS): status-Bits 0-7: 00000110
ACCI st Brk Err mp-Bits 0-7: 00110000

4698 - Function Restriction due to Faults in Other Modules
U1113 00 [047] - -
Confirmed - Tested Since Memory Clear
Freeze Frame:
Fault Status: 00000001
Fault Priority: 2
Fault Frequency: 4
Mileage: 200318 km
Date: 2021.10.08
Time: 16:58:17

Engine RPM: 639.00 /min
Normed load value: 37.3 %
Vehicle speed: 0 km/h
Coolant temperature: 63 °C
Intake air temperature: 27 °C
Ambient air pressure: 1000 mbar
Voltage terminal 30: 14.160 V
Unlearning counter according OBD: 40
Crankshaft speed (RPM): 639.0 /min
Vehicle speed: 0.00 km/h
Cruise Control System: specified speed: 0.00 km/h
CCS status-Bits 0-7: 11110100
Cr Ctl st Shut Offirev-Bits 0-7: 00000000
Cr Ctl st Shut Offrev-Bits 0-7: 00000000
Cr Ctl st Shut Offrev-Bits 0-7: 00000000
Cr Ctl st Shut Offrev-Bits 0-7: 00000110
Cr Ctl st Shut Offrev-Bits 0-7: 01000000
Cr C st Key 0-Bits 0-7: 00000000
Cr C st Key 0-Bits 0-7: 00000000

4699 - Function Restriction due to Faults in Other Modules
U1113 00 [047] - -
Confirmed - Tested Since Memory Clear
Freeze Frame:
Fault Status: 00000001
Fault Priority: 2
Fault Frequency: 4
Mileage: 200318 km
Date: 2021.10.08
Time: 16:58:17

Engine RPM: 639.00 /min
Normed load value: 37.3 %
Vehicle speed: 0 km/h
Coolant temperature: 63 °C
Intake air temperature: 27 °C
Ambient air pressure: 1000 mbar
Voltage terminal 30: 14.160 V
Unlearning counter according OBD: 40
Crankshaft speed (RPM): 639.0 /min
Vehicle speed: 0.00 km/h
Cruise Control System: specified speed: 0.00 km/h
CCS status-Bits 0-7: 11110100
Cr Ctl st Shut Offirev-Bits 0-7: 00000000
Cr Ctl st Shut Offrev-Bits 0-7: 00000000
Cr Ctl st Shut Offrev-Bits 0-7: 00000000
Cr Ctl st Shut Offrev-Bits 0-7: 00000110
Cr Ctl st Shut Offrev-Bits 0-7: 01000000
Cr C st Key 0-Bits 0-7: 00000000
Cr C st Key 0-Bits 0-7: 00000000

Readiness: 0 0 0 0 0

-------------------------------------------------------------------------------
Address 02: Auto Trans (J217) Labels:| 0AW-927-156.clb
Part No SW: 8K0 927 155 C HW: 0AW 927 156 E
Component: 0AW 27 TDIRdW H03 0006
Revision: --H03--- Serial number: 0000000013
Coding: 000001
Shop #: WSC 06325 000 00000
ASAM Dataset: EV_TCMVL381 A01009
ROD: EV_TCMVL381_A01.rod
VCID: 3365AACB9A3561130E-8066

No fault code found.

-------------------------------------------------------------------------------
Address 03: ABS Brakes (J104) Labels:. 8K0-907-379-V1.clb
Part No SW: 8K0 907 379 M HW: 8K0 907 379 M
Component: ESP8 front H03 0210
Revision: -------- Serial number: --------------
Coding: 1A6D00
Shop #: WSC 80093 222 69422
VCID: 4385FA0BC295D1939E-8016

3 Faults Found:
01486 - System Function Test Activated
000 - -
Freeze Frame:
Fault Status: 01100000
Fault Priority: 4
Fault Frequency: 1
Reset counter: 53
Mileage: 200323 km
Time Indication: 0
Date: 2021.10.08
Time: 17:36:05

Freeze Frame:
Hex Value: 0x0000
Hex Value: 0x47A2
Hex Value: 0x0015
Hex Value: 0x31B4
Hex Value: 0x00FF

03110 - Active Steering Control Module (J792)
013 - Check DTC Memory
Freeze Frame:
Fault Status: 01101101
Fault Priority: 6
Fault Frequency: 1
Reset counter: 53
Mileage: 200323 km
Time Indication: 0
Date: 2021.10.08
Time: 17:36:07

Freeze Frame:
Hex Value: 0x0000
Hex Value: 0x42A2
Hex Value: 0x000D
Hex Value: 0x33B4
Hex Value: 0x00FF

03159 - TPMS Functionality in ESP
000 - -
Freeze Frame:
Fault Status: 01100000
Fault Priority: 4
Fault Frequency: 1
Reset counter: 53
Mileage: 200323 km
Time Indication: 0
Date: 2021.10.08
Time: 17:36:07

Freeze Frame:
Hex Value: 0x0000
Hex Value: 0x42A2
Hex Value: 0x001A
Hex Value: 0x0DB4
Hex Value: 0x00FF

-------------------------------------------------------------------------------
Address 05: Acc/Start Auth. (J393) Labels:. 8K0-907-064-05.clb
Part No SW: 8K0 907 064 D HW: 8K0 907 064 D
Component: BCM2 1.1 H70 0134
Revision: 00002001
Coding: 050100
Shop #: WSC 06325 000 00000
VCID: 3169A0C3682953037C-8064

Subsystem 1 - Part No SW: 8K0 905 852 C HW: 8K0 905 852 C
Component: ELVAUDIB8 H35 0039
Serial number: 0207000001824009

5 Faults Found:
03287 - Sensors for Contact with Door Handles
010 - Open or Short to Plus
Freeze Frame:
Fault Status: 01101010
Fault Priority: 2
Fault Frequency: 5
Reset counter: 53
Mileage: 200242 km
Time Indication: 0
Date: 2021.10.05
Time: 17:59:48

01330 - Central Control Module for Central Convenience (J393)
013 - Check DTC Memory - Intermittent
Freeze Frame:
Fault Status: 00101101
Fault Priority: 6
Fault Frequency: 4
Reset counter: 91
Mileage: 200242 km
Time Indication: 0
Date: 2021.10.05
Time: 18:01:08

03286 - Sensor for Contact with Door Handle; Front Right
007 - Short to Ground
Freeze Frame:
Fault Status: 01100111
Fault Priority: 2
Fault Frequency: 1
Reset counter: 51
Mileage: 200269 km
Time Indication: 0
Date: 2021.10.06
Time: 09:49:54

00193 - Rear Right Door Handle Touch Sensor (G418)
007 - Short to Ground - Intermittent
Freeze Frame:
Fault Status: 00100111
Fault Priority: 2
Fault Frequency: 1
Reset counter: 91
Mileage: 200269 km
Time Indication: 0
Date: 2021.10.06
Time: 10:14:02

03285 - Sensor for Contact with Door Handle; Front Left
007 - Short to Ground
Freeze Frame:
Fault Status: 01100111
Fault Priority: 2
Fault Frequency: 1
Reset counter: 51
Mileage: 200269 km
Time Indication: 0
Date: 2021.10.07
Time: 07:37:02

-------------------------------------------------------------------------------
Address 07: Control Head Labels: 8T0-035-7xx-07-H.clb
Part No SW: 8T0 035 729 F HW: 4E0 035 729 A
Component: Interfacebox H43 4690
Revision: 00000000 Serial number: 331KS077515706
Coding: 0000006
Shop #: WSC 06325 000 00000
VCID: 3C7781F77F6BAE6BDF-8068

Subsystem 1 - Part No: 8T0 919 609 C
Component: E0380 BedienteilH08 0100

Subsystem 2 - Serial number: 00000000027424

Subsystem 3 - Serial number: 0112.11.070000000100010103˙

Subsystem 4 - Serial number: 010103˙

No fault code found.

-------------------------------------------------------------------------------
Address 08: Auto HVAC (J255) Labels:. 8Tx-820-043-3Z.clb
Part No SW: 8T1 820 043 S HW: 8T1 820 043 S
Component: KLIMA 3 ZONEN H05 0120
Revision: C3000000 Serial number: 0108.11.070190
Coding: 36000002
Shop #: WSC 06325 000 00000
VCID: 4189F003D889C3838C-8014

No fault code found.

-------------------------------------------------------------------------------
Address 09: Cent. Elect. (J519) Labels:. 8K0-907-063.clb
Part No SW: 8K0 907 063 D HW: 8K0 907 063 D
Component: BCM1 1.0 H21 0253
Revision: 05021001 Serial number: 00000000050085
Coding: 2600D0914014AF311F01000000001D0D0F9CC34800010145000000
Shop #: WSC 02170 995 88267
VCID: 306FA5C763235A0B73-8064

Subsystem 1 - Part No SW: 8K1 955 119 HW: 8T1 955 119 Labels: 1KX-955-119.CLB
Component: WWS 121107 H06 0060
Serial number: SWFBIE 0000427
Coding: 00FD11

Subsystem 2 - Part No SW: 8K0 955 559 HW: 8K0 955 559 Labels: 8K0-955-559.CLB
Component: RLS H04 0002
Serial number: 10021517
Coding: 025028

Subsystem 3 - Part No SW: 8K0 941 531 G HW: 8K0 941 531 G
Component: E1 - LDS H07 0070
Serial number: 00000000001409070171

Subsystem 4 - Part No SW: 8K0 959 772 HW: 8K0 959 772
Component: SLR-B8 H04 0002
Serial number: 1100051515
Coding: 0F0000

1 Fault Found:
03123 - Terminal 30 - 2
011 - Open Circuit
Freeze Frame:
Fault Status: 01101011
Fault Priority: 2
Fault Frequency: 1
Reset counter: 53
Mileage: 200323 km
Time Indication: 0
Date: 2021.10.08
Time: 17:36:00

-------------------------------------------------------------------------------
Address 0E: Media Player 1 Labels: 4E0-910-111.lbl
Part No SW: 8T1 035 110 B HW: 8T1 035 110 A
Component: MP3-Changer H41 0380
Revision: 00041003 Serial number: AUZ5ZBG4041518
Shop #: WSC 00000 000 00000
VCID: 295948A380F92BC3B4-807C

No fault code found.

-------------------------------------------------------------------------------
Address 10: Park/Steer Assist (J446) Labels:. 8K0-919-475.clb
Part No SW: 8K0 919 475 C HW: 8K0 919 475 A
Component: PARKHILFE 8K H06 0010
Revision: 11001001 Serial number: 75230732507444
Coding: 300103
Shop #: WSC 06325 000 00000
VCID: 397998E3B0599B43C4-806C

No fault code found.

-------------------------------------------------------------------------------
Address 13: Auto Dist. Reg (J428) Labels: None
Part No SW: 8K0 907 561 HW: 8K0 907 561
Component: ACC2 H07 0080
Serial number: 00000000000000
Coding: 0079C0
Shop #: WSC 00460 259 179486
VCID: 6FED66BBBE9D05F32A-803A

4 Faults Found:
00234 - Sensor for Automatic Distance Regulation Misadjusted
000 - -
Freeze Frame:
Fault Status: 01100000
Fault Priority: 2
Fault Frequency: 1
Reset counter: 51
Mileage: 200239 km
Time Indication: 0
Date: 2021.10.05
Time: 17:31:22

Freeze Frame:
Temperature: 35.0°C
Voltage: 12.03 V
Bin. Bits: 01011
Hex Value: 0x0941
Hex Value: 0x0001
Speed: 0.0 km/h
Lateral Accel.: 0.00 m/s^2

01314 - Engine Control Module
013 - Check DTC Memory
Freeze Frame:
Fault Status: 01101101
Fault Priority: 6
Fault Frequency: 46
Reset counter: 53
Mileage: 200239 km
Time Indication: 0
Date: 2021.10.05
Time: 17:31:22

Freeze Frame:
Temperature: 35.0°C
Voltage: 12.03 V
Bin. Bits: 01011
Hex Value: 0x044B
Hex Value: 0x0013
Speed: 0.0 km/h
Lateral Accel.: 0.00 m/s^2

03110 - Active Steering Control Module (J792)
013 - Check DTC Memory - Intermittent
Freeze Frame:
Fault Status: 00101101
Fault Priority: 6
Fault Frequency: 1
Reset counter: 91
Mileage: 200239 km
Time Indication: 0
Date: 2021.10.05
Time: 17:44:02

Freeze Frame:
Temperature: 32.0°C
Voltage: 13.44 V
Bin. Bits: 00011
Hex Value: 0x044B
Hex Value: 0x0038
Speed: 3.6 km/h
Lateral Accel.: -0.37 m/s^2

01316 - ABS Control Module
013 - Check DTC Memory
Freeze Frame:
Fault Status: 01101101
Fault Priority: 6
Fault Frequency: 64
Reset counter: 53
Mileage: 200240 km
Time Indication: 0
Date: 2021.10.05
Time: 17:52:56

Freeze Frame:
Temperature: 29.0°C
Voltage: 11.90 V
Bin. Bits: 01011
Hex Value: 0x044B
Hex Value: 0x0015
Speed: 0.0 km/h
Lateral Accel.: 0.00 m/s^2

-------------------------------------------------------------------------------
Address 14: Susp. Elect. (J250) Labels: None
Part No SW: 8K0 907 364 HW: 8K0 907 364
Component: DAEMPFUNGS-SG H06 0044
Revision: 00000000 Serial number: 23100700160001
Coding: 070181
Shop #: WSC 06325 000 00000
VCID: 70EF65C7A3A31A0B33-8024

No fault code found.

-------------------------------------------------------------------------------
Address 15: Airbags (J234) Labels:| 8K0-959-655.clb
Part No SW: 8K0 959 655 B HW: 8K0 959 655 B
Component: AirbagVW-AU10 H23 0409
Serial number: 0038JD11EF3Y
Coding: 30343434363030303030554A304C384B3053
Shop #: WSC 06325 000 00000
ASAM Dataset: EV_AirbaECUVWAUDI010 A02001
ROD: EV_AirbaECUVWAUDI010_A02.rod
VCID: 3C7781F7B76BAE6BDF-8068

Crash sensor for side airbag: driver side:
Serial number: 6334MSME3151430C2

Front Passenger's Side Airbag Crash Sensor:
Serial number: 6344MSME31770B1FJ

Rear Side Airbag Crash Sensor (on driver's side):
Serial number: 6352QSME4202382FD

Passenger side rear thorax airbag crash sensor:
Serial number: 6362QSME47334C5BR

Crash sensor for front airbag: driver side:
Serial number: 63732SME461B0E05/

Crash sensor for front airbag: front passenger side:
Serial number: 63832SME44711A49/

No fault code found.

-------------------------------------------------------------------------------
Address 16: Steering wheel (J527) Labels:. 8K0-953-568.clb
Part No SW: 8K0 953 568 G HW: 8K0 953 568 G
Component: Lenks.Modul H16 0014
Revision: -------- Serial number: 90304IGG0008E
Coding: 0000BE
Shop #: WSC 02724 128 28888
VCID: 3E738BFFA977BC7BF1-806A

Component: E221 - MFL H01 0003

1 Fault Found:
02795 - Steering Wheel Vibration Motor (V331)
011 - Open Circuit - Intermittent
Freeze Frame:
Fault Status: 00101011
Fault Priority: 3
Fault Frequency: 2
Reset counter: 91
Mileage: 200269 km
Time Indication: 0
Date: 2021.10.06
Time: 18:01:47

-------------------------------------------------------------------------------
Address 17: Instruments (J285) Labels:. 8T0-920-xxx-17.clb
Part No SW: 8K0 920 930 J HW: 8K0 920 930 J
Component: KOMBIINSTR. H13 0214
Revision: 00000000 Serial number: 7C315X5C7
Coding: 0306080077000008030000
Shop #: WSC 06325 123 12345
VCID: 3467A9D7973B662B17-8060

No fault code found.

-------------------------------------------------------------------------------
Address 19: CAN Gateway (J533) Labels:. 8T0-907-468.clb
Part No SW: 8T0 907 468 G HW: 8T0 907 468 G
Component: GW-BEM 5CAN-M H08 0084
Revision: FB102034 Serial number: 3400F07A168121
Coding: 000003
Shop #: WSC 00024 000 00000
VCID: 4581E413CCA1EFA3B0-8010

Subsystem 1 - Part No SW: 8K0 915 181 HW: 8K0 915 181
Component: J367-BDM H06 0150
Serial number: 17007304071107

No fault code found.

-------------------------------------------------------------------------------
Address 1B: Active Steering (J792) Labels: None
Part No SW: 8K0 907 144 A HW: 8K0 907 144 A
Component: DYNAMIKLENK. H05 0322
Revision: 50000003 Serial number: --------------
Coding: 0C0000
Shop #: WSC 06325 000 00000
VCID: 2D51BCB3741137E358-8078

No fault code found.

-------------------------------------------------------------------------------
Address 36: Seat Mem. Drvr (J136) Labels:. 8T0-959-760.clb
Part No SW: 8K0 959 760 A HW: 8K0 959 760 A
Component: MEM-FS H05 0043
Revision: AA000000 Serial number: 00001001047780
Coding: C0581B000F0044110000
Shop #: WSC 06325 000 00000
VCID: 387F9DE78B53824B3B-806C

1 Fault Found:
03332 - Motor for Height Adjustment
005 - No or Incorrect Basic Setting / Adaptation
Freeze Frame:
Fault Status: 01100101
Fault Priority: 4
Fault Frequency: 1
Reset counter: 50
Mileage: 200217 km
Time Indication: 0
Date: 2021.09.26
Time: 08:03:41

-------------------------------------------------------------------------------
Address 37: Navigation Labels: 4E0-910-88x-37.lbl
Part No SW: 4E0 910 887 T HW: 4E0 919 887 M
Component: MNS ECE H50 1030
Revision: 00000000 Serial number: 333K2077527898
Shop #: WSC 06342 000 00000
VCID: 3E738BFF6977BC7BF1-806A

No fault code found.

-------------------------------------------------------------------------------
Address 3C: Lane Change Labels: None
Part No SW: 8K0 907 566 HW: 4L0 907 566 A
Component: J0769_SWA_MasterH10 0040
Revision: 00H10000 Serial number: 6PZ 009 014-02
Coding: 0000101
Shop #: WSC 00186 785 00200
VCID: 74E769D717BB262BD7-8020

Subsystem 1 - Part No: 8K0 907 568
Component: J0770_SWA_Slave_H08 0040

Subsystem 2 - Serial number: 6PZ 009 014-22

Subsystem 3 - Serial number: 3F16.11.0700H0800000010002˙

Subsystem 4 - Serial number: 010002˙

1 Fault Found:
16365 - Control Module - Electrical Error; CPU 2
014 - Defective
Freeze Frame:
Fault Status: 01101110
Fault Priority: 3
Fault Frequency: 1
Reset counter: 53
Mileage: 200323 km
Time Indication: 0
Date: 2021.10.08
Time: 17:32:17

-------------------------------------------------------------------------------
Address 42: Door Elect, Driver (J386) Labels:. 8K0-959-793.clb
Part No SW: 8K0 959 793 B HW: 8K0 959 793
Component: TSG FA H10 0170
Revision: Serial number: 0000006688022
Coding: 011C12205E00410001
Shop #: WSC 06342 000 00000
VCID: 3F8DF6FBAE7DB573FA-806A

No fault code found.

-------------------------------------------------------------------------------
Address 46: Central Conv. (J393) Labels:. 8K0-907-064-46.clb
Part No SW: 8K0 907 064 D HW: 8K0 907 064 D
Component: BCM2 1.1 H70 0134
Revision: 00002001 Serial number: 0107336484
Coding: 01000E2000390481012001
Shop #: WSC 06342 000 00000
VCID: 3169A0C3682953037C-8064

7 Faults Found:
02615 - Fuel Tank Cap; Lock
009 - Open or Short to Ground
Freeze Frame:
Fault Status: 01101001
Fault Priority: 2
Fault Frequency: 1
Reset counter: 50
Mileage: 200217 km
Time Indication: 0
Date: 2021.09.26
Time: 08:21:30

02616 - Fuel Tank Cap; Unlock
009 - Open or Short to Ground
Freeze Frame:
Fault Status: 01101001
Fault Priority: 2
Fault Frequency: 1
Reset counter: 50
Mileage: 200217 km
Time Indication: 0
Date: 2021.09.26
Time: 08:22:25

01504 - Bulb for License-Plate Light (X)
012 - Electrical Fault in Circuit - Intermittent
Freeze Frame:
Fault Status: 00101100
Fault Priority: 2
Fault Frequency: 9
Reset counter: 92
Mileage: 200221 km
Time Indication: 0
Date: 2021.09.26
Time: 08:57:46

01316 - ABS Control Module
004 - No Signal/Communication - Intermittent
Freeze Frame:
Fault Status: 00100100
Fault Priority: 6
Fault Frequency: 4
Reset counter: 91
Mileage: 200242 km
Time Indication: 0
Date: 2021.10.05
Time: 18:01:08

00466 - Control Module for Steering Column Electronics (J527)
004 - No Signal/Communication - Intermittent
Freeze Frame:
Fault Status: 00100100
Fault Priority: 6
Fault Frequency: 5
Reset counter: 91
Mileage: 200269 km
Time Indication: 0
Date: 2021.10.06
Time: 07:33:28

00166 - Access/Start Authorization Switch (E415)
008 - Implausible Signal - Intermittent
Freeze Frame:
Fault Status: 00101000
Fault Priority: 2
Fault Frequency: 1
Reset counter: 91
Mileage: 200269 km
Time Indication: 0
Date: 2021.10.07
Time: 07:37:01

01519 - Bulb for Back-Up Lights; Right (M17)
012 - Electrical Fault in Circuit - Intermittent
Freeze Frame:
Fault Status: 00101100
Fault Priority: 2
Fault Frequency: 1
Reset counter: 93
Mileage: 200318 km
Time Indication: 0
Date: 2021.10.08
Time: 17:06:23

-------------------------------------------------------------------------------
Address 47: Sound System (J525) Labels:. 8T0-035-223-BOM.clb
Part No SW: 8T0 035 223 M HW: 8T0 035 223 C
Component: DSP Prem H12 0280
Revision: 00H12003 Serial number: 34813001012602
Coding: 020101
Shop #: WSC 12336 024 394758
VCID: 387F9DE78B53824B3B-806C

No fault code found.

-------------------------------------------------------------------------------
Address 52: Door Elect, Pass. (J387) Labels:. 8K0-959-792.clb
Part No SW: 8K0 959 792 B HW: 8K0 959 792
Component: TSG BF H10 0170
Revision: Serial number: 0000006702982
Coding: 011C12205E00410001
Shop #: WSC 06325 000 00000
VCID: 3E738BFFA977BC7BF1-806A

No fault code found.

-------------------------------------------------------------------------------
Address 53: Parking Brake (J540) Labels: 8K0-907-801-V1.clb
Part No SW: 8K0 907 801 C HW: 8K0 907 801 C
Component: EPB Audi B8 H03 0040
Revision: 00000003 Serial number: 00000000033536
Shop #: WSC 00000 000 00000
VCID: 2F6DA6BB7E1D45F36A-807A

No fault code found.

-------------------------------------------------------------------------------
Address 55: Headlight Range Labels: 8K0-907-357.clb
Part No: 8K0 907 357 B
Component: Dynamische LWR H01 0030
Revision: 00000001 Serial number:
Coding: 0000005
Shop #: WSC 04170 995 94292
VCID: 3467A9D7573B662B17-8060

2 Faults Found:
02988 - Left-Hand/Right-Hand Traffic Switchover Active
000 - - - MIL ON
Freeze Frame:
Fault Status: 11100000
Fault Priority: 7
Fault Frequency: 1
Reset counter: 50
Mileage: 200217 km
Time Indication: 0
Date: 2021.09.26
Time: 08:13:31

01535 - Control Circuit for Right Headlight Range Adjusting Motor (V49)
010 - Open or Short to Plus - Intermittent
Freeze Frame:
Fault Status: 00101010
Fault Priority: 7
Fault Frequency: 1
Reset counter: 90
Mileage: 200224 km
Time Indication: 0
Date: 2021.09.28
Time: 16:38:22

-------------------------------------------------------------------------------
Address 56: Radio Labels: 4E0-910-541.lbl
Part No SW: 4E0 910 541 Q HW: 4F0 035 541 L
Component: TUNER EU/US/RDW H42 0620
Revision: 00000000 Serial number: 336K 077525197
Coding: 0000001
Shop #: WSC 06325 000 00000
VCID: 2E53BBBFB9174CFB61-807A

No fault code found.

-------------------------------------------------------------------------------
Address 5C: Lane Maintain. Labels: None
Part No SW: 8K0 907 217 A HW: 4E0 907 217 C
Component: J759 LDW 0070
Revision: 00H06006 Serial number: 8002079190006C
Coding: 0003001
Shop #: WSC 02170 995 88267
VCID: 2E53BBBFB9174CFB61-807A

1 Fault Found:
02797 - Control Module for Directional Stabilization Assistance (J759)
005 - No or Incorrect Basic Setting / Adaptation
Freeze Frame:
Fault Status: 01100101
Fault Priority: 3
Fault Frequency: 1
Reset counter: 53
Mileage: 200323 km
Time Indication: 0
Date: 2021.10.08
Time: 17:38:50

-------------------------------------------------------------------------------
Address 62: Door, Rear Left (J388) Labels:. 8K0-959-795.clb
Part No SW: 8K0 959 795 HW: 8K0 959 795
Component: TSG HL H06 0170
Revision: Serial number: 0000006679717
Coding: 010C12204000210001
Shop #: WSC 06325 000 00000
VCID: 7F0DB6FBEEFD7573BA-802A

1 Fault Found:
00446 - Function Limitation due to Under-Voltage
000 - - - Intermittent
Freeze Frame:
Fault Status: 00100000
Fault Priority: 3
Fault Frequency: 2
Reset counter: 91
Mileage: 200269 km
Time Indication: 0
Date: 2021.10.06
Time: 09:54:41

-------------------------------------------------------------------------------
Address 6C: Back-up Cam. Labels: 8T0-907-441.clb
Part No SW: 8T0 907 441 A HW: 4L0 907 441 A
Component: J772__Rearview 0050
Revision: --H12--- Serial number: 525PA8-J7X80U5
Coding: 1021006
Shop #: WSC 06435 000 00000
VCID: 366393DF4147743B29-8062

1 Fault Found:
00466 - Control Module for Steering Column Electronics (J527)
004 - No Signal/Communication - Intermittent
Freeze Frame:
Fault Status: 00100100
Fault Priority: 6
Fault Frequency: 14
Reset counter: 91
Mileage: 200269 km
Time Indication: 0
Date: 2021.10.06
Time: 07:33:27

Freeze Frame:
Term 15 Off
Reverse OFF
Count: 3

-------------------------------------------------------------------------------
Address 72: Door, Rear Right (J389) Labels:. 8K0-959-794.clb
Part No SW: 8K0 959 794 HW: 8K0 959 795
Component: TSG HR H06 0170
Revision: Serial number: 0000006683847
Coding: 010C12204000210001
Shop #: WSC 06325 000 00000
VCID: 7EF34BFFE9F77C7BB1-802A

No fault code found.

-------------------------------------------------------------------------------
Address 77: Telephone Labels: 4E0-910-336.lbl
Part No SW: 4E0 910 336 K HW: 4E0 862 335
Component: Handyvorb2 H18 0950
Revision: 00000000 Serial number: 00000005058545
Coding: 0010930
Shop #: WSC 06325 000 00000
VCID: 2A5BB7AF85FF20DBBD-807E

1 Fault Found:
00003 - Control Module
014 - Defective
Freeze Frame:
Fault Status: 11101110
Fault Priority: 9
Fault Frequency: 254
Reset counter: 255
Time Indication: 9

End-------------------------(Elapsed Time: 04:13)--------------------------

Ogólnie to w tym momencie nawet przestało działać wspomaganie, a wszystko zaczęło się od skrzypnięcia przy skręceniu w lewo. VCDS podpowiada mi aby sprawdzić moduł od aktywnego sterowania, gdzie on się znajduje?

Jeszcze wpadł mi do głowy ten modułJ527, czy jest to ten moduł w który " wciska " się cały zwijacz z taśmą?

Edytowane 8 Października 2021 przez AudiA4B827

**Muskel1** · 8 Października 2021

Ten błąd w sterowniku 09 (bcm1)

1 Fault Found:
03123 - Terminal 30 - 2
011 - Open Circuit

może być przyczyną. Oznacza to, że nie ma napięcia na zacisku 30/2 zasilającego min. sterownik.

Sprawdź wszystkie bezpieczniki.

**AudiA4B827** · 9 Października 2021

11 godzin temu, Muskel1 napisał:

Ten błąd w sterowniku 09 (bcm1)

1 Fault Found:
03123 - Terminal 30 - 2
011 - Open Circuit

może być przyczyną. Oznacza to, że nie ma napięcia na zacisku 30/2 zasilającego min. sterownik.

Sprawdź wszystkie bezpieczniki.

Dzięki wielkie, problem w połowie rozwiązany.

Mimo, że bezpiecznik był dobry to wyjęcie i włożenie pomogło - wróciło : Klimatyzacja, oświetlenie, wspomaganie i zniknęło troche błędów.

Niestety nie rozwiązało to problemów z ESP + TPMS + ABS + Aktywne Sterowanie. Obecny skan wygląda następująco : ABS pokazuje błąd w J792, a w nim cisza Czujnik kąta skrętu sprawdzałem, wraz ze skręcaniem kierownicy wartości się zmieniają.

01-Engine -- Status: Malfunction 0010
02-Auto Trans -- Status: OK 0000
03-ABS Brakes -- Status: Malfunction 0010
04-Steering Angle -- Status: OK 0000
05-Acc/Start Auth. -- Status: OK 0000
07-Control Head -- Status: OK 0000
08-Auto HVAC -- Status: OK 0000
09-Cent. Elect. -- Status: OK 0000
0E-Media Player 1 -- Status: OK 0000
10-Park/Steer Assist -- Status: OK 0000
13-Auto Dist. Reg -- Status: Malfunction 0010
14-Susp. Elect. -- Status: OK 0000
15-Airbags -- Status: OK 0000
16-Steering wheel -- Status: OK 0000
17-Instruments -- Status: OK 0000
19-CAN Gateway -- Status: OK 0000
1B-Active Steering -- Status: OK 0000
36-Seat Mem. Drvr -- Status: Malfunction 0010
37-Navigation -- Status: OK 0000
3C-Lane Change -- Status: Malfunction 0010
42-Door Elect, Driver -- Status: OK 0000
46-Central Conv. -- Status: OK 0000
47-Sound System -- Status: OK 0000
52-Door Elect, Pass. -- Status: OK 0000
53-Parking Brake -- Status: OK 0000
55-Headlight Range -- Status: Malfunction 0010
56-Radio -- Status: OK 0000
5C-Lane Maintain. -- Status: Malfunction 0010
62-Door, Rear Left -- Status: OK 0000
6C-Back-up Cam. -- Status: OK 0000
72-Door, Rear Right -- Status: OK 0000
77-Telephone -- Status: Malfunction 0010

-------------------------------------------------------------------------------
Address 01: Engine (J623-CAMA) Labels:| 059-907-401-V1.clb
Part No SW: 8K1 907 401 D HW: 8K0 907 401
Component: 2.7TDI EDC17 H01 0004
Revision: --H01---
Coding: 0104002C02070220
Shop #: WSC 80093 222 69422
ASAM Dataset: EV_ECM27TDI8K1907401D A01004
ROD: EV_ECM27TDI8K1907401D.rod
VCID: 2D51BCB37C1137E358-8078

3 Faults Found:
4327 - Function Restriction due to Faults in Other Modules
U1113 00 [039] - -
Not Confirmed - Tested Since Memory Clear
Freeze Frame:
Fault Status: 00000001
Fault Priority: 2
Fault Frequency: 1
Mileage: 200339 km
Date: 2021.10.09
Time: 09:21:50

Engine RPM: 655.50 /min
Normed load value: 36.9 %
Vehicle speed: 0 km/h
Coolant temperature: 62 °C
Intake air temperature: 19 °C
Ambient air pressure: 1000 mbar
Voltage terminal 30: 14.000 V
Unlearning counter according OBD: 40
Crankshaft speed (RPM): 655.5 /min
Vehicle speed: 0.00 km/h
Acceleration: 0.000 m/s˛
ACCI a Des: 0.007 m/s˛
ACCI st State-Bits 0-7: 00000011
Cruise Control System (CCS): status-Bits 0-7: 00000110
ACCI st Brk Err mp-Bits 0-7: 00110000

4698 - Function Restriction due to Faults in Other Modules
U1113 00 [039] - -
Not Confirmed - Tested Since Memory Clear
Freeze Frame:
Fault Status: 00000001
Fault Priority: 2
Fault Frequency: 2
Mileage: 200339 km
Date: 2021.10.09
Time: 09:21:50

Engine RPM: 655.50 /min
Normed load value: 36.9 %
Vehicle speed: 0 km/h
Coolant temperature: 62 °C
Intake air temperature: 19 °C
Ambient air pressure: 1000 mbar
Voltage terminal 30: 14.000 V
Unlearning counter according OBD: 40
Crankshaft speed (RPM): 655.5 /min
Vehicle speed: 0.00 km/h
Cruise Control System: specified speed: 0.00 km/h
CCS status-Bits 0-7: 11110101
Cr Ctl st Shut Offirev-Bits 0-7: 00000000
Cr Ctl st Shut Offrev-Bits 0-7: 00000000
Cr Ctl st Shut Offrev-Bits 0-7: 00000000
Cr Ctl st Shut Offrev-Bits 0-7: 00000110
Cr Ctl st Shut Offrev-Bits 0-7: 01000000
Cr C st Key 0-Bits 0-7: 00000000
Cr C st Key 0-Bits 0-7: 00000000

4699 - Function Restriction due to Faults in Other Modules
U1113 00 [039] - -
Not Confirmed - Tested Since Memory Clear
Freeze Frame:
Fault Status: 00000001
Fault Priority: 2
Fault Frequency: 2
Mileage: 200339 km
Date: 2021.10.09
Time: 09:21:50

Engine RPM: 655.50 /min
Normed load value: 36.9 %
Vehicle speed: 0 km/h
Coolant temperature: 62 °C
Intake air temperature: 19 °C
Ambient air pressure: 1000 mbar
Voltage terminal 30: 14.000 V
Unlearning counter according OBD: 40
Crankshaft speed (RPM): 655.5 /min
Vehicle speed: 0.00 km/h
Cruise Control System: specified speed: 0.00 km/h
CCS status-Bits 0-7: 11110101
Cr Ctl st Shut Offirev-Bits 0-7: 00000000
Cr Ctl st Shut Offrev-Bits 0-7: 00000000
Cr Ctl st Shut Offrev-Bits 0-7: 00000000
Cr Ctl st Shut Offrev-Bits 0-7: 00000110
Cr Ctl st Shut Offrev-Bits 0-7: 01000000
Cr C st Key 0-Bits 0-7: 00000000
Cr C st Key 0-Bits 0-7: 00000000

Readiness: 0 0 0 0 1

-------------------------------------------------------------------------------
Address 02: Auto Trans (J217) Labels:| 0AW-927-156.clb
Part No SW: 8K0 927 155 C HW: 0AW 927 156 E
Component: 0AW 27 TDIRdW H03 0006
Revision: --H03--- Serial number: 0000000013
Coding: 000001
Shop #: WSC 06325 000 00000
ASAM Dataset: EV_TCMVL381 A01009
ROD: EV_TCMVL381_A01.rod
VCID: 3365AACB9A3561130E-8066

No fault code found.

-------------------------------------------------------------------------------
Address 03: ABS Brakes (J104) Labels:. 8K0-907-379-V1.clb
Part No SW: 8K0 907 379 M HW: 8K0 907 379 M
Component: ESP8 front H03 0210
Revision: -------- Serial number: --------------
Coding: 1A6D00
Shop #: WSC 80093 222 69422
VCID: 4385FA0BC295D1939E-8016

3 Faults Found:
01486 - System Function Test Activated
000 - -
Freeze Frame:
Fault Status: 01100000
Fault Priority: 4
Fault Frequency: 1
Reset counter: 54
Mileage: 200339 km
Time Indication: 0
Date: 2021.10.09
Time: 09:22:30

Freeze Frame:
Hex Value: 0x0000
Hex Value: 0x47A2
Hex Value: 0x0015
Hex Value: 0x31B4
Hex Value: 0x00FF

03110 - Active Steering Control Module (J792)
013 - Check DTC Memory
Freeze Frame:
Fault Status: 01101101
Fault Priority: 6
Fault Frequency: 1
Reset counter: 54
Mileage: 200339 km
Time Indication: 0
Date: 2021.10.09
Time: 09:22:32

Freeze Frame:
Hex Value: 0x0000
Hex Value: 0x42A2
Hex Value: 0x000D
Hex Value: 0x33B4
Hex Value: 0x00FF

03159 - TPMS Functionality in ESP
000 - -
Freeze Frame:
Fault Status: 01100000
Fault Priority: 4
Fault Frequency: 1
Reset counter: 54
Mileage: 200339 km
Time Indication: 0
Date: 2021.10.09
Time: 09:22:32

Freeze Frame:
Hex Value: 0x0000
Hex Value: 0x42A2
Hex Value: 0x001A
Hex Value: 0x0DB4
Hex Value: 0x00FF

-------------------------------------------------------------------------------
Address 05: Acc/Start Auth. (J393) Labels:. 8K0-907-064-05.clb
Part No SW: 8K0 907 064 D HW: 8K0 907 064 D
Component: BCM2 1.1 H70 0134
Revision: 00002001
Coding: 050100
Shop #: WSC 06325 000 00000
VCID: 3169A0C3682953037C-8064

Subsystem 1 - Part No SW: 8K0 905 852 C HW: 8K0 905 852 C
Component: ELVAUDIB8 H35 0039
Serial number: 0207000001824009

No fault code found.

-------------------------------------------------------------------------------
Address 07: Control Head Labels: 8T0-035-7xx-07-H.clb
Part No SW: 8T0 035 729 F HW: 4E0 035 729 A
Component: Interfacebox H43 4690
Revision: 00000000 Serial number: 331KS077515706
Coding: 0000006
Shop #: WSC 06325 000 00000
VCID: 3C7781F77F6BAE6BDF-8068

Subsystem 1 - Part No: 8T0 919 609 C
Component: E0380 BedienteilH08 0100

Subsystem 2 - Serial number: 00000000027424

Subsystem 3 - Serial number: 0112.11.070000000100010103˙

Subsystem 4 - Serial number: 010103˙

No fault code found.

-------------------------------------------------------------------------------
Address 08: Auto HVAC (J255) Labels:. 8Tx-820-043-3Z.clb
Part No SW: 8T1 820 043 S HW: 8T1 820 043 S
Component: KLIMA 3 ZONEN H05 0120
Revision: C3000000 Serial number: 0108.11.070190
Coding: 36000002
Shop #: WSC 06325 000 00000
VCID: 4189F003D889C3838C-8014

No fault code found.

-------------------------------------------------------------------------------
Address 09: Cent. Elect. (J519) Labels:. 8K0-907-063.clb
Part No SW: 8K0 907 063 D HW: 8K0 907 063 D
Component: BCM1 1.0 H21 0253
Revision: 05021001 Serial number: 00000000050085
Coding: 2600D0914014AF311F01000000001D0D0F9CC34800010145000000
Shop #: WSC 02170 995 88267
VCID: 306FA5C763235A0B73-8064

Subsystem 1 - Part No SW: 8K1 955 119 HW: 8T1 955 119 Labels: 1KX-955-119.CLB
Component: WWS 121107 H06 0060
Serial number: SWFBIE 0000427
Coding: 00FD11

Subsystem 2 - Part No SW: 8K0 955 559 HW: 8K0 955 559 Labels: 8K0-955-559.CLB
Component: RLS H04 0002
Serial number: 10021517
Coding: 025028

Subsystem 3 - Part No SW: 8K0 941 531 G HW: 8K0 941 531 G
Component: E1 - LDS H07 0070
Serial number: 00000000001409070171

Subsystem 4 - Part No SW: 8K0 959 772 HW: 8K0 959 772
Component: SLR-B8 H04 0002
Serial number: 1100051515
Coding: 0F0000

No fault code found.

-------------------------------------------------------------------------------
Address 0E: Media Player 1 Labels: 4E0-910-111.lbl
Part No SW: 8T1 035 110 B HW: 8T1 035 110 A
Component: MP3-Changer H41 0380
Revision: 00041003 Serial number: AUZ5ZBG4041518
Shop #: WSC 00000 000 00000
VCID: 295948A380F92BC3B4-807C

No fault code found.

-------------------------------------------------------------------------------
Address 10: Park/Steer Assist (J446) Labels:. 8K0-919-475.clb
Part No SW: 8K0 919 475 C HW: 8K0 919 475 A
Component: PARKHILFE 8K H06 0010
Revision: 11001001 Serial number: 75230732507444
Coding: 300103
Shop #: WSC 06325 000 00000
VCID: 397998E3B0599B43C4-806C

No fault code found.

-------------------------------------------------------------------------------
Address 13: Auto Dist. Reg (J428) Labels: None
Part No SW: 8K0 907 561 HW: 8K0 907 561
Component: ACC2 H07 0080
Serial number: 00000000000000
Coding: 0079C0
Shop #: WSC 00460 259 179486
VCID: 6FED66BBBE9D05F32A-803A

3 Faults Found:
00234 - Sensor for Automatic Distance Regulation Misadjusted
000 - -
Freeze Frame:
Fault Status: 01100000
Fault Priority: 2
Fault Frequency: 1
Reset counter: 54
Mileage: 200339 km
Time Indication: 0
Date: 2021.10.09
Time: 09:24:04

Freeze Frame:
Temperature: 20.0°C
Voltage: 14.59 V
Bin. Bits: 00011
Hex Value: 0x0941
Hex Value: 0x0001
Speed: 0.0 km/h
Lateral Accel.: 0.00 m/s^2

01314 - Engine Control Module
013 - Check DTC Memory
Freeze Frame:
Fault Status: 01101101
Fault Priority: 6
Fault Frequency: 1
Reset counter: 54
Mileage: 200339 km
Time Indication: 0
Date: 2021.10.09
Time: 09:24:04

Freeze Frame:
Temperature: 20.0°C
Voltage: 14.59 V
Bin. Bits: 00011
Hex Value: 0x044B
Hex Value: 0x0013
Speed: 0.0 km/h
Lateral Accel.: 0.00 m/s^2

01316 - ABS Control Module
013 - Check DTC Memory
Freeze Frame:
Fault Status: 01101101
Fault Priority: 6
Fault Frequency: 2
Reset counter: 54
Mileage: 200339 km
Time Indication: 0
Date: 2021.10.09
Time: 09:24:04

Freeze Frame:
Temperature: 20.0°C
Voltage: 14.59 V
Bin. Bits: 00011
Hex Value: 0x044B
Hex Value: 0x0015
Speed: 0.0 km/h
Lateral Accel.: 0.00 m/s^2

-------------------------------------------------------------------------------
Address 14: Susp. Elect. (J250) Labels: None
Part No SW: 8K0 907 364 HW: 8K0 907 364
Component: DAEMPFUNGS-SG H06 0044
Revision: 00000000 Serial number: 23100700160001
Coding: 070181
Shop #: WSC 06325 000 00000
VCID: 70EF65C7A3A31A0B33-8024

No fault code found.

-------------------------------------------------------------------------------
Address 15: Airbags (J234) Labels:| 8K0-959-655.clb
Part No SW: 8K0 959 655 B HW: 8K0 959 655 B
Component: AirbagVW-AU10 H23 0409
Serial number: 0038JD11EF3Y
Coding: 30343434363030303030554A304C384B3053
Shop #: WSC 06325 000 00000
ASAM Dataset: EV_AirbaECUVWAUDI010 A02001
ROD: EV_AirbaECUVWAUDI010_A02.rod
VCID: 3C7781F7B76BAE6BDF-8068

Crash sensor for side airbag: driver side:
Serial number: 6334MSME3151430C2

Front Passenger's Side Airbag Crash Sensor:
Serial number: 6344MSME31770B1FJ

Rear Side Airbag Crash Sensor (on driver's side):
Serial number: 6352QSME4202382FD

Passenger side rear thorax airbag crash sensor:
Serial number: 6362QSME47334C5BR

Crash sensor for front airbag: driver side:
Serial number: 63732SME461B0E05/

Crash sensor for front airbag: front passenger side:
Serial number: 63832SME44711A49/

No fault code found.

-------------------------------------------------------------------------------
Address 16: Steering wheel (J527) Labels:. 8K0-953-568.clb
Part No SW: 8K0 953 568 G HW: 8K0 953 568 G
Component: Lenks.Modul H16 0014
Revision: -------- Serial number: 90304IGG0008E
Coding: 0000BE
Shop #: WSC 02724 128 28888
VCID: 3E738BFFA977BC7BF1-806A

Component: E221 - MFL H01 0003

No fault code found.

-------------------------------------------------------------------------------
Address 17: Instruments (J285) Labels:. 8T0-920-xxx-17.clb
Part No SW: 8K0 920 930 J HW: 8K0 920 930 J
Component: KOMBIINSTR. H13 0214
Revision: 00000000 Serial number: 7C315X5C7
Coding: 0306080077000008030000
Shop #: WSC 06325 123 12345
VCID: 3467A9D7973B662B17-8060

No fault code found.

-------------------------------------------------------------------------------
Address 19: CAN Gateway (J533) Labels:. 8T0-907-468.clb
Part No SW: 8T0 907 468 G HW: 8T0 907 468 G
Component: GW-BEM 5CAN-M H08 0084
Revision: FB102034 Serial number: 3400F07A168121
Coding: 000003
Shop #: WSC 00024 000 00000
VCID: 4581E413CCA1EFA3B0-8010

Subsystem 1 - Part No SW: 8K0 915 181 HW: 8K0 915 181
Component: J367-BDM H06 0150
Serial number: 17007304071107

No fault code found.

-------------------------------------------------------------------------------
Address 1B: Active Steering (J792) Labels: None
Part No SW: 8K0 907 144 A HW: 8K0 907 144 A
Component: DYNAMIKLENK. H05 0322
Revision: 50000003 Serial number: --------------
Coding: 0C0000
Shop #: WSC 06325 000 00000
VCID: 2D51BCB3741137E358-8078

No fault code found.

-------------------------------------------------------------------------------
Address 36: Seat Mem. Drvr (J136) Labels:. 8T0-959-760.clb
Part No SW: 8K0 959 760 A HW: 8K0 959 760 A
Component: MEM-FS H05 0043
Revision: AA000000 Serial number: 00001001047780
Coding: C0581B000F0044110000
Shop #: WSC 06325 000 00000
VCID: 387F9DE78B53824B3B-806C

1 Fault Found:
03332 - Motor for Height Adjustment
005 - No or Incorrect Basic Setting / Adaptation
Freeze Frame:
Fault Status: 01100101
Fault Priority: 4
Fault Frequency: 1
Reset counter: 54
Mileage: 200339 km
Time Indication: 0
Date: 2021.10.09
Time: 09:26:06

-------------------------------------------------------------------------------
Address 37: Navigation Labels: 4E0-910-88x-37.lbl
Part No SW: 4E0 910 887 T HW: 4E0 919 887 M
Component: MNS ECE H50 1030
Revision: 00000000 Serial number: 333K2077527898
Shop #: WSC 06342 000 00000
VCID: 3E738BFF6977BC7BF1-806A

No fault code found.

-------------------------------------------------------------------------------
Address 3C: Lane Change Labels: None
Part No SW: 8K0 907 566 HW: 4L0 907 566 A
Component: J0769_SWA_MasterH10 0040
Revision: 00H10000 Serial number: 6PZ 009 014-02
Coding: 0000101
Shop #: WSC 00186 785 00200
VCID: 74E769D717BB262BD7-8020

Subsystem 1 - Part No: 8K0 907 568
Component: J0770_SWA_Slave_H08 0040

Subsystem 2 - Serial number: 6PZ 009 014-22

Subsystem 3 - Serial number: 3F16.11.0700H0800000010002˙

Subsystem 4 - Serial number: 010002˙

1 Fault Found:
16365 - Control Module - Electrical Error; CPU 2
014 - Defective
Freeze Frame:
Fault Status: 01101110
Fault Priority: 3
Fault Frequency: 1
Reset counter: 54
Mileage: 200339 km
Time Indication: 0
Date: 2021.10.09
Time: 09:21:11

-------------------------------------------------------------------------------
Address 42: Door Elect, Driver (J386) Labels:. 8K0-959-793.clb
Part No SW: 8K0 959 793 B HW: 8K0 959 793
Component: TSG FA H10 0170
Revision: Serial number: 0000006688022
Coding: 011C12205E00410001
Shop #: WSC 06342 000 00000
VCID: 3F8DF6FBAE7DB573FA-806A

No fault code found.

-------------------------------------------------------------------------------
Address 46: Central Conv. (J393) Labels:. 8K0-907-064-46.clb
Part No SW: 8K0 907 064 D HW: 8K0 907 064 D
Component: BCM2 1.1 H70 0134
Revision: 00002001 Serial number: 0107336484
Coding: 01000E2000390481012001
Shop #: WSC 06342 000 00000
VCID: 3169A0C3682953037C-8064

No fault code found.

-------------------------------------------------------------------------------
Address 47: Sound System (J525) Labels:. 8T0-035-223-BOM.clb
Part No SW: 8T0 035 223 M HW: 8T0 035 223 C
Component: DSP Prem H12 0280
Revision: 00H12003 Serial number: 34813001012602
Coding: 020101
Shop #: WSC 12336 024 394758
VCID: 387F9DE78B53824B3B-806C

No fault code found.

-------------------------------------------------------------------------------
Address 52: Door Elect, Pass. (J387) Labels:. 8K0-959-792.clb
Part No SW: 8K0 959 792 B HW: 8K0 959 792
Component: TSG BF H10 0170
Revision: Serial number: 0000006702982
Coding: 011C12205E00410001
Shop #: WSC 06325 000 00000
VCID: 3E738BFFA977BC7BF1-806A

No fault code found.

-------------------------------------------------------------------------------
Address 53: Parking Brake (J540) Labels: 8K0-907-801-V1.clb
Part No SW: 8K0 907 801 C HW: 8K0 907 801 C
Component: EPB Audi B8 H03 0040
Revision: 00000003 Serial number: 00000000033536
Shop #: WSC 00000 000 00000
VCID: 2F6DA6BB7E1D45F36A-807A

No fault code found.

-------------------------------------------------------------------------------
Address 55: Headlight Range Labels: 8K0-907-357.clb
Part No: 8K0 907 357 B
Component: Dynamische LWR H01 0030
Revision: 00000001 Serial number:
Coding: 0000005
Shop #: WSC 04170 995 94292
VCID: 3467A9D7573B662B17-8060

1 Fault Found:
02988 - Left-Hand/Right-Hand Traffic Switchover Active
000 - - - MIL ON
Freeze Frame:
Fault Status: 11100000
Fault Priority: 7
Fault Frequency: 1
Reset counter: 54
Mileage: 200339 km
Time Indication: 0
Date: 2021.10.09
Time: 09:27:35

-------------------------------------------------------------------------------
Address 56: Radio Labels: 4E0-910-541.lbl
Part No SW: 4E0 910 541 Q HW: 4F0 035 541 L
Component: TUNER EU/US/RDW H42 0620
Revision: 00000000 Serial number: 336K 077525197
Coding: 0000001
Shop #: WSC 06325 000 00000
VCID: 2E53BBBFB9174CFB61-807A

No fault code found.

-------------------------------------------------------------------------------
Address 5C: Lane Maintain. Labels: None
Part No SW: 8K0 907 217 A HW: 4E0 907 217 C
Component: J759 LDW 0070
Revision: 00H06006 Serial number: 8002079190006C
Coding: 0003001
Shop #: WSC 02170 995 88267
VCID: 2E53BBBFB9174CFB61-807A

1 Fault Found:
02797 - Control Module for Directional Stabilization Assistance (J759)
005 - No or Incorrect Basic Setting / Adaptation
Freeze Frame:
Fault Status: 01100101
Fault Priority: 3
Fault Frequency: 1
Reset counter: 54
Mileage: 200339 km
Time Indication: 0
Date: 2021.10.09
Time: 09:27:59

-------------------------------------------------------------------------------
Address 62: Door, Rear Left (J388) Labels:. 8K0-959-795.clb
Part No SW: 8K0 959 795 HW: 8K0 959 795
Component: TSG HL H06 0170
Revision: Serial number: 0000006679717
Coding: 010C12204000210001
Shop #: WSC 06325 000 00000
VCID: 7F0DB6FBEEFD7573BA-802A

No fault code found.

-------------------------------------------------------------------------------
Address 6C: Back-up Cam. Labels: 8T0-907-441.clb
Part No SW: 8T0 907 441 A HW: 4L0 907 441 A
Component: J772__Rearview 0050
Revision: --H12--- Serial number: 525PA8-J7X80U5
Coding: 1021006
Shop #: WSC 06435 000 00000
VCID: 366393DF4147743B29-8062

No fault code found.

-------------------------------------------------------------------------------
Address 72: Door, Rear Right (J389) Labels:. 8K0-959-794.clb
Part No SW: 8K0 959 794 HW: 8K0 959 795
Component: TSG HR H06 0170
Revision: Serial number: 0000006683847
Coding: 010C12204000210001
Shop #: WSC 06325 000 00000
VCID: 7EF34BFFE9F77C7BB1-802A

No fault code found.

-------------------------------------------------------------------------------
Address 77: Telephone Labels: 4E0-910-336.lbl
Part No SW: 4E0 910 336 K HW: 4E0 862 335
Component: Handyvorb2 H18 0950
Revision: 00000000 Serial number: 00000005058545
Coding: 0010930
Shop #: WSC 06325 000 00000
VCID: 2A5BB7AF85FF20DBBD-807E

1 Fault Found:
00003 - Control Module
014 - Defective
Freeze Frame:
Fault Status: 11101110
Fault Priority: 9
Fault Frequency: 254
Reset counter: 255
Time Indication: 9

End-------------------------(Elapsed Time: 04:08)--------------------------

**Muskel1** · 9 Października 2021

Z pewnego powodu (pewnie z braku zasilania) uruchomił Ci się test drogowy ESP, dlatego te błędy w sterowniku ABS widnieją i nie dają się wykasować. Musisz w takim razie przeprowadzić do kńca pozytywnie ten uruchomioy test ESP.

Tu masz 2 filmiki.

**AudiA4B827** · 9 Października 2021

21 godzin temu, Muskel1 napisał:

Z pewnego powodu (pewnie z braku zasilania) uruchomił Ci się test drogowy ESP, dlatego te błędy w sterowniku ABS widnieją i nie dają się wykasować. Musisz w takim razie przeprowadzić do kńca pozytywnie ten uruchomioy test ESP.

Tu masz 2 filmiki.

Dzięki wielkie, temat zaraz wykonam tylko złożę kierownicę. Mam jeszcze pytanie odnośnie silnika wibracyjnego i jego braku przejścia, podłączyłem go na krótko, silniczek działa. Ale zaciekawiło mnie, że z jednej strony wtyczki są 3 kable a z drugiej. Wygląda to tak. Ktoś zmieniał przyciski i założył od wersji bez silniczka drgań? Wdg. schematu WRClaguny, powinno być 5 kabli. Może ktoś to potwierdzić?

EDIT @

Test wykonywałem jak na filmikach, bez zmian nie da rady go ukończyć, prawdopodobnie przy tych błędach

Edit 2 @#@#@

Dostałem się do modułu j792 pod podłogą, w środku sucho, kable ładne, piny czyste. Patrząc po schematach i okolicznościach w jakich problem nastąpił, stwierdzam awarie jednego z czujników na kolumnie kierowniczej. Niestety nie wiem jak on się nazywa i czy jest wymienny, dostęp też tragiczny, pewnie trzeba będzie wyciągać całą kolumne. Jakieś porady odnośnie demontażu?

Edytowane 10 Października 2021 przez AudiA4B827

**AudiA4B827** · 13 Października 2021

Dzisiejszego dnia wymieniłem kolumne kierowniczą, brak efektu.

-Wyjąłem sterownik J792 z myślą, że może gdzieś zmoknął, - nic z tych rzeczy, piny wszystkie w stanie idealnym, sterownik suchy. Już powoli zaczynam mieć dosyć ... :facepalm:

Pompa ABS/ESP może dawać taki błąd bo szlak ją trafił? Przejrzałem prawie cały internet i nigdzie nie widzę tego błędu z dopiskiem w sprawdzeniu j792.

**AudiA4B827** · 21 Października 2021

Kolumna kierownicza jak wyżej pisałem wymieniona, wiązki sprawdzone, podmieniony moduł j792 i błędy zniknęły !

Test Esp odrazu udało się wykonać ( Abs zniknął )

ESP + TMPS również !

W elektrycznym zawieszeniu + silniku brak błędów o blokowaniu różnych funkcji ! W ABS nic !

Audi Drive Select działa jak trzeba( zmienia twardość kierownicy w zależności od trybu jazdy ).

Jedyny problem jest taki, że w 1B jest błąd o złym zakodowaniu sterownika ( niestety VCDS nie pozwala mi tam pogrzebać ) ale kod mogę wprowadzić. Sterownik używany, zostaje ASO? Czy ktoś może posiada jakiś kod aby to poprawnie zakodować ? Chciałem udać się na kalibrację radaru oraz kamery, lecz w ACC jest również ten błąd o złym kodowaniu 1B. Prawdopodobnie nie da rady przez to przeprowadzić kalibracji

**marek323** · 5 Lutego 2022

Witam, dzisiaj również pojawił się u mnie błąd 03110 i przestało działać aktywne wspomaganie. Pacjent to a5 2010r, miałem problem z abs, esp, hamulcem postojowym i poziomowaniem świateł. Sprawdzałem bezpieczniki jednak były sprawne. Uszkodzony okazał się tylko czujnik abs więc go wymieniłem i wszystkie stare usterki zniknęły jednak pojawił się problem z dynamicznym wspomaganiem. Próbowałem kodować Byte 7 na kanale 09 zaznaczając dynamic/active steering installed jednak nadal nie działa i wyskakuje wyżej wspomniany błąd. Co mogę zrobić w takiej sytuacji?

Zaloguj się

03110 - Active Steering Control Module = ABS TMPS

Rekomendowane odpowiedzi

AudiA4B827

wrclaguna

AudiA4B827

Muskel1

AudiA4B827

Muskel1

AudiA4B827

Muskel1

AudiA4B827

AudiA4B827

AudiA4B827

marek323

Jeśli chcesz dodać odpowiedź, zaloguj się lub zarejestruj nowe konto

Zarejestruj nowe konto

Zaloguj się

Ostatnio przeglądający 0 użytkowników

Tematy

Ogłoszenia

Cała aktywność
